Yageo RC_L Series – General Purpose Thick Film Chip Resistors

The Yageo RC_L Series resistors are general-purpose thick film chip resistors designed with lead-free terminations and manufactured using a thick film process. Built on a high-grade ceramic body, these resistors deliver high reliability, wide resistance range, and stable performance, making them ideal for diverse electronic applications.

Technical Specifications

Parameter Value
Resistance Range 1 Ω to 100 MΩ (E24 & E96 values)
Case Sizes Available 0075, 0100, 0201, 0402, 0603, 0805, 1206, 1210, 1218, 2010, 2512
Rated Voltage 10V – 200V
Max Power Rating Up to 2W
Tolerance Options ±0.1%, ±0.5%, ±1%, ±5%
Operating Temp. Range -55°C to +155°C (RC0402–RC2512) / -55°C to +125°C (RC0075–RC0201)

Key Features

  • Wide resistance range: 1 Ω to 100 MΩ

  • Multiple EIA case sizes for design flexibility

  • Space-saving small chip sizes for compact PCBs

  • High reliability for components & equipment

  • RoHS compliant (forbidden materials not used)

  • Stable performance across wide temperature range

Applications

  • Consumer electronics

  • Industrial equipment

  • Automotive electronics

  • Communication devices

  • General-purpose electronic circuits
