PIC12F675-I/SN Microcontroller by Microchip | 8-Bit MCU, 1.75KB Flash, SOIC-8 Package
MICROCHIP
PIC12F675-I/SN Microcontroller – Microchip
The PIC12F675-I/SN is an 8-bit microcontroller from Microchip Technology, featuring 1.75 KB Flash memory, 64 bytes of SRAM, and 128 bytes of EEPROM for versatile data storage. It operates with an internal 4 MHz oscillator and includes a 10-bit ADC, watchdog timer, and comparators, making it suitable for a wide range of applications. Packaged in a compact SOIC-8, it is ideal for space-constrained, low-power designs in automotive, industrial, appliance, and consumer electronics that require field re-programmability.
Technical Specifications
| Parameter | Value / Description |
|---|---|
| Core | 8-bit PIC® MCU |
| Program Memory (Flash) | 1.75 KB |
| RAM | 64 bytes |
| EEPROM | 128 bytes |
| CPU Speed | Up to 20 MHz (with internal/external oscillator) |
| I/O Pins | 6 |
| ADC | 10-bit, 4 channels |
| Comparators | 1 |
| Timers | 1 × 16-bit, 1 × 8-bit |
| Watchdog Timer | Yes |
| Operating Voltage | 2.0 V – 5.5 V |
| Package | SOIC-8 |
| Temperature Range | –40 °C to +85 °C |
Key Features
-
Compact 8-pin SOIC package
-
1.75 KB Flash, 64B SRAM, and 128B EEPROM
-
Integrated 10-bit ADC and comparator
-
Internal oscillator with up to 20 MHz operation
-
Wide 2.0V–5.5V operating range
-
Field re-programmable for flexible deployment
Applications
-
Automotive electronics
-
Industrial controllers
-
Household appliances
-
Consumer entry-level products
-
Portable and battery-powered devices
