P600D 6A 200V General Purpose Rectifier Diode | R-6 Package | Fast Recovery | Efficient Rectification

The P600D Rectifier Diode supports 6A forward current and 200V reverse voltage, designed for efficient power conversion. It offers low power loss, high reliability, and a durable R-6 package for robust operation.

🔧 Key Specifications:

• Part Number: P600D

• Average Forward Current (IF): 6.0A

• Maximum Reverse Voltage (VR): 200V

• Peak Forward Surge Current (IFSM): 400A

• Forward Voltage Drop (VF): 1.0V (typ.)

• Reverse Current (IR): 5µA

• Package: R-6

• Operating Temperature: −55°C to +150°C

💡 Features & Benefits:

• High surge current capacity

• Efficient rectification with low voltage loss

• Thermally robust construction

• Reliable long-term performance

⚙️ Applications:

• Power converters

• Battery chargers

• Power supply rectifiers

• Industrial electronic circuits
