The HUSG-4.000-16-20/30Y is a 4 MHz half-size quartz crystal oscillator in a compact 2-pin through-hole package with dimensions of 10.7 × 4.3 × 3.5 mm. Designed for stable and accurate frequency control, it is widely used in clock generation, timing circuits, and embedded electronic applications.

With a load capacitance of 16 pF, the crystal ensures ±20 ppm frequency tolerance at 25°C and ±30 ppm frequency stability across -20°C to +70°C, making it a reliable solution for consumer, industrial, and communication systems.

Key Features:

• Frequency: 4 MHz

• Package size: 10.7 × 4.3 × 3.5 mm (Half-size, 2-pin through-hole)

• Load capacitance: 16 pF

• Frequency tolerance: ±20 ppm @ 25°C

• Frequency stability: ±30 ppm (-20°C ~ +70°C)

• Operating temperature range: -20°C ~ +70°C

• Storage temperature range: -50°C ~ +105°C

Applications:

• Microcontroller clock sources

• Timing circuits and oscillators

• Consumer electronics

• Industrial and communication equipment
