DSU047N15NA 150V 175A N-Channel Power MOSFET – TOLL | WXDH

The WXDH 150V N-Channel Power MOSFET series is built using advanced SGT (Shielded Gate Trench) technology to deliver high efficiency, low conduction losses, and robust performance in medium- to high-voltage power applications. With a drain-source voltage rating of 150V and a wide current range up to 180A, these MOSFETs are optimized for demanding switching environments requiring both high power density and reliability.

This series features low RDS(on), fast switching characteristics, and optimized gate charge, enabling improved system efficiency and reduced thermal stress. The devices are available in a broad range of package options including DFN5×6, TO-220, TO-263, TO-252, TOLL, TO-247, and TO-3PN, providing flexibility for both surface-mount and through-hole designs.

Designed for high-performance applications, these MOSFETs ensure stable operation under high load conditions, excellent heat dissipation, and long-term reliability. Their rugged construction and advanced process technology make them ideal for modern power conversion and control systems.

Applications

• Switching power supplies (SMPS)

• DC-DC converters

• Motor control systems

• Industrial power management

• Solar inverters and energy systems

• Battery management systems (BMS)

Features

• Advanced SGT (Shielded Gate Trench) technology

• Low RDS(on) for reduced power loss

• High current capability up to 180A

• Fast switching performance

• Wide range of package options

• Excellent thermal efficiency

  • High reliability for industrial applications
