MF72 10D-9 Thermistor – Inrush Current Limiter
The MF72 10D-9 is a Negative Temperature Coefficient (NTC) thermistor designed to act as an inrush current limiter, protecting electronic circuits from high surge currents during power-on. With its high initial resistance, it effectively reduces the inrush current and then gradually decreases in resistance as it heats up, ensuring stable circuit operation. Compact, reliable, and durable, this component is widely used in power supplies, transformers, motor drives, and other electronic equipment requiring inrush current protection.
Technical Specifications
| Parameter | Value / Description |
|---|---|
| Part Number | MF72 10D-9 |
| Type | NTC Thermistor |
| Application | Inrush Current Limiter |
| Nominal Resistance (at 25°C) | 10 Ω |
| Diameter | 9 mm |
| Operating Temperature | -40°C to +125°C (typical) |
| Function | High initial resistance for surge suppression, lowers resistance during normal operation |
| Package | Radial Lead |
Key Features
-
High inrush current suppression capability
-
Compact 9 mm disc design for space-saving PCB integration
-
Stable and reliable thermal response
-
Helps protect power supplies, transformers, and electronic circuits
-
Long operating life and high reliability
-
RoHS compliant
Applications
-
Switched-mode power supplies (SMPS)
-
LED drivers & ballasts
-
Transformer protection
-
Audio/video equipment
-
Industrial and consumer electronics
